hYDRAULIC hose Standard - JIS Inserts

H122389Z

90° JIs Female 60° B
8363 seat Flare (type F)
seLeCTIoN ChART

FeRRULe item Code Part number Hose iD Hose iD DAsH F Thread F Thread C CUT-oFF D DroP CH2

mm
DAsH
in
mm
in-TPi
Factor
mm
6,4
1203095
9,5
33
06
06
22
31,8
3/8-19
3/8
H122389Z-060600
1203094
36,5
1203093 H122389Z-040400 1/4 12,7 04 1/4-19 04 27,7 29,5 19
1/2-14
08
37,5
H122389Z-080800
27
1/2
08
1203092 H122389Z-121200 3/4 19 12 3/4-14 12 50 47 36
1203091 H122389Z-161600 1 25,4 16 1-11 16 76,4 64,5 41
